Introduction
| Type: | Single Hole Terminals |
|---|---|
| Material: | Silver-Plated Copper |
| Application: | Conduct Electricity, Transmission of Electrical Signals |
| Character: | Insulation |
| Species: | Housing |
| Production Process: | Injection Molding |
Specification:
| Model | TH180 |
| Rated Voltage | 600V |
| Rated Current | 180A |
| Wiring Section | 1/0.2/4AWG (53.5mm2 to 33.6/21.2mm2) |
| Contact Resistence | 0.05MΩ |
| Withstand Voltage | 2200VDC |
| Insulation Resistence | 500MΩ |
| None Load(contact/disconnect cycles) | up to 10000 |
| Under Load(hot plug 250ºC cycle@120V) | 75A |
| Average Insertion Force | 110N |
| Fire Resistence Level of Housing | UL94 V-0 |
| Working Temperature | -20ºC to 125ºC |
| Contacts material | Copper Silver Plated |
